제품 목록
Photo Model Standard Catalogue
15152 측정범위
- start/ end of rain
Supply voltage
-24VAC/DC /max.4W
Collecting surface
- 40㎠ sensor surface
하우징
IP65
운용환경
- -30…50℃ 		PDF 다운로드
SA10 Supply
24 Vac/dc (22…28 V), < 5 VA
Measuring range
weak rain approx. 1 V, < 0.5 mm/h
normal rain approx. 2…3 V
heavy rain approx. 3…10 V
Output
0…10 V, 2 mA
Relay contact
normally open contact 60 Vdc 0.1 A
Ambient temperature
-40…+50 °C 		PDF 다운로드
RD30 measuring
principle Electrolytic AC measurement

input current
12V model 60 mA, heater 80 - 300 mA (PTC)
24V model 50 mA, heater 40 - 180 mA (PTC)

output
Isolated relay switching output 30V/ 4A,
optional: NO/NC contact 		PDF 다운로드
RD-11 측정방식 : 임피던스 검출식
감지 면적 : 9 ㎠
감지면 각도 : 30°
감지도 : 0.05 ㎠
감지면 : 금박 GRID (3 ㎛)
케이블 : 4Wire or 3Wire (3m)
보호기능 : 낙뢰 보호기능
히터 : 자동조절
크기/중량 : 60 x 150 x 70 mm / 500g 		PDF 다운로드
